ZXHN F601 je GPON optički mrežni terminal (ONT) u skladu sa ITU-T G.984.x i G.988 standardima, sa jednim 10/100/1000 Mbps Ethernet portom za FTTH scenario, i obezbeđuje 2.488 Gbps nizvodno i 1.244 Gbps uzvodno GPON uplink interfejs.
| Items | ZXHN F601 |
| Wavelength | Receiving: 1480~1500 nm Transmitting: 1290~1330 nm |
| Receiving Sensitivity | -28dBm |
| Transmitting Optical Power | 0.5~5dBm |
| Power consumption | <6W |
| Dimensions | 110mm(W) x 90mm(H) x 53mm(D) |
| Working temperature | 0oC ~ 40oC |
| Working humidity | 5% ~ 95% |
| Power supply | 12V DC |
| Mounting mode | Desktop/Wall mounting |
| Supported service | Internet, IPTV |
| Multicast group per user port | 256 |
| QoS | service flow classification based on physical port, Ethernet type; ingress rate limit; egress shaping |
