The V-SOL V3212 is an L3 managed 12-port Ethernet switch with 10G SFP+ uplink ports, designed for complex network solutions. It is ideal for the core or distribution layer in enterprise networks, ISP environments, data centers, and networks with high demands for throughput and scalability. It supports Layer 3 routing, VLANs, advanced security features, QoS, port aggregation, and numerous network protocols, enabling complete control, stability, and flexibility of the network. The metal casing with a cooling fan ensures reliable and stable operation.
| Feature / Parameter | Value / Description |
| Model | V3212 |
| Type | L3 Managed 10G Ethernet Switch |
| Ports | 12 × 10G SFP+ uplink ports, 1 × Console Port |
| Switching Capacity | 240 Gbps |
| Throughput | 178.56 Mpps |
| RAM / Flash | 128 MB DDR SDRAM / 16 MB Flash |
| MAC Address Table | Up to 32,000 entries |
| Jumbo Frame | Up to 12 KB |
| VLAN Support | Up to 4096 VLANs |
| Dimensions | 440 × 205 × 44 mm |
| Weight | 2.5 kg |
| Power Consumption | < 30 W |
| Operating Temperature | -10 °C to +40 °C |
| Operating Humidity | 10–90% non-condensing |
| Layer 3 Functions | IPv4/IPv6 Routing, ARP, RIPv1/v2, OSPF |
| Advanced Network Functions | Link Aggregation, VLAN, MAC-VLAN, Private VLAN, DHCP server/relay, ACL, dynamic ARP checking, IP source guard, DoS protection, STP/RSTP/MSTP, ERPS, loop detection, QoS, port mirroring, port isolation, rate-limit, SNMP, IGMP snooping, MLD, multicast router port, MVR, Q-in-Q, LLDP, logs, configuration backup/restore, firmware update |
