| Weight (without power adapter) |
Approximately 400 g |
| Dimensions (H x W x D) |
32 x 200 x 127 mm |
| Operating Temperature |
0–40℃ |
| Operating Humidity |
5–95% relative humidity (non-condensing) |
| Power Adapter Input |
100–240V AC, 50/60 Hz |
| UNI |
2 POTS + 4 GE + 2.4G/5G Wi-Fi + 1 USB |
| NNI |
1 x GPON |
| Maximum Power Consumption |
18 W |
| Placement Mode |
Standing |
| GPON Port |
|
| – Connector |
SC/APC |
| – Class |
B+ |
| – Receiver Sensitivity |
–27 dBm |
| – Optical Overload Power |
–8 dBm |
| – Bi-directional FEC |
(Forward Error Correction) |
| – SR-DBA and NSR-DBA |
|
| – Type B |
(single and dual homing) |
| Ethernet Electrical Port |
|
| – VLAN tagging |
based on Ethernet port and tag removal |
| – 1:1 VLAN, N:1 VLAN, |
or transparent VLAN transmission |
| – QinQ VLAN |
|
| – MAC address learning limit |
|
| – MAC address learning |
|
| – Auto-negotiation speeds |
10 Mbit/s, 100 Mbit/s, or 1000 Mbit/s |
| POTS Port |
|
| – Encoding/decoding |
G.711A/μ, G.729a/b, and G.722 |
| – Fax modes |
T.30/T.38/G.711 |
| – DTMF |
|
| – Emergency calls |
(using SIP protocol) |
| Wireless Network (WLAN) |
|
| – IEEE 802.11 |
b/g/n (2.4G), IEEE 802.11 a/n/ac (5G) |
| – 2 x 2 MIMO |
(2.4G & 5G), 4 x 4 MIMO (2.4G & 5G) |
| – Antenna gain |
5 dBi |
| – WMM/Multiple SSIDs/WPS |
|
| – Simultaneous 2.4G and 5G |
|
| – Air interface speeds |
600 Mbit/s (2.4G), 1733 Mbit/s (5G) |
| Energy Saving |
CoC V7 |
