| Item | H805GPFD |
|---|
| GPON Port | 16-GPON Port |
| GPON SFP Module Specification |
| Type | B+ Module: Single-directional module, Class B+ |
| C+ Module: Single-directional module, Class C+ |
| C++ Module: Single-directional module, Class C++ |
| Operating Wavelength | Tx: 1490 nm, Rx: 1310 nm |
| Encapsulation Type | SFP |
| Port Speed | B+: 2.49 Gbit/s, Reception Speed: 1.24 Gbit/s |
| C+: 2.49 Gbit/s, Reception Speed: 1.24 Gbit/s |
| C++: Tx: 2.488 Gbit/s, Rx: 1.244 Gbit/s |
| Minimum Output Optical Power | B+: 1.5 dBm |
| C+: 3 dBm |
| C++: 6 dBm |
| Maximum Output Optical Power | B+: 5 dBm |
| C+: 7 dBm |
| C++: 10 dBm |
| Maximum Reception Sensitivity | B+: -28 dBm |
| C+: -32 dBm |
| C++: -35 dBm |
| Optical Connector Type | SC/PC |
| Optical Fiber Type | Single-mode |
| Range | 20.00 km |
| Optical Power Overload | B+: -8 dBm |
| C+: -12 dBm |
| C++: -15 dBm |
| Light Turn-off Ratio | 8.2 dB |
| Power Consumption and Maximum Frame Size |
| Power Consumption | Static: H802GPFD: 45 W, Maximum: 73 W |
| H803GPFD: Static: 39 W, Maximum: 61 W |
| H805GPFD: Static: 26 W, Maximum: 50 W |
| Maximum Frame Size | 2004 bytes |
| Operating Temperature | -25°C to +65°C |
| Dimensions (W x D x H) | 22.86 mm x 237.00 mm x 395.40 mm |
