| Aspect | Value |
|---|---|
| Product Name | Switch (24 ports) |
| License | DNA license not included and must be ordered separately. Please contact your sales representative. |
| Performance | Switching Capacity: 56 Gbps Total Multilayer Throughput: 320 Gbps Stacking Bandwidth: 376 Gbps Forwarding Rate: 41.66 Mpps Stacking Forwarding Rate: 279.76 Mpps |
| Encryption Algorithm | 128-bit AES, 256-bit AES |
| Routing Protocol | OSPF, RIP-1, RIP-2, EIGRP, VRRP, PIM-SM, EIGRP for IPv6, OSPFv3, PIM-SSM, Policy-Based Routing (PBR), RIPng, MSTP |
| PoE Budget | 505 W |
| Jumbo Frames Support | 9198 bytes |
| Ports | 24 x 10/100/1000 (PoE+) 4 x Gigabit SFP (Uplink) |
| MAC Address Table Size | 32,000 entries |
| Compliance with Standards | IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.1ae, IEEE 802.3at, IEEE 1588v2, IEEE 802.1BA, Wi-Fi CERTIFIED 6 |
| Subtype | Gigabit Ethernet |
| Features | ACL support, QoS, Rapid Per-VLAN Spanning Tree Plus (PVRST+), SRR, PXE support, Energy Efficient Ethernet, CoS, FNF, 802.1x authentication, DSCP support, MACsec support, CoPP, Blue Beacon LED, Zero-touch provisioning (ZTP), Secure Boot, PIM, FHS, PVLAN support |
| Construction | Original |
| Housing Type | Rack mount |
| Remote Management Protocols | SNMP 1, RMON 1, RMON 2, SNMP 3, SNMP 2c, CLI, NETCONF, RESTCONF, gRPC, IPv4, IPv6, YANG |
| Capacity | IPv4 routes: 32,000 IPv6 routes: 16,000 Multicast entries: 8,000 QoS scaling entries: 5,120 ACL entries: 5,120 VLAN support: 4,094> FNF entries: 64,000 SVI: 1,000 Buffer size: 16 MB VLANs: 64 |
| Device Type | Managed Layer 3 Switch with 24 ports, stackable capability |
