| DNA License |
DNA license is not included and must be ordered separately. Please contact your contact person. |
| Performance |
Switching Capacity: 56 Gbit/s <br> Total Bandwidth: 320 Gbit/s <br> Stack Bandwidth: 376 Gbit/s <br> Forwarding Rate: 41.66 Mpps <br> Stack Forwarding Rate: 279.76 Mpps |
| Encryption Algorithm |
128-bit AES, 256-bit AES |
| Routing Protocol |
OSPF, RIP-1, RIP-2, EIGRP, VRRP, PIM-SM, EIGRP for IPv6, OSPFv3, PIM-SSM, Policy-Based Routing (PBR), RIPng, MSTP |
| PoE Budget |
505 W |
| Jumbo Frame Support |
9198 bytes |
| Ports |
24 x 10/100/1000 (PoE+) + 4 x Gigabit SFP (Uplink) |
| MAC Address Table Size |
32,000 entries |
| Compliance Standards |
IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.1ae, IEEE 802.3at, IEEE 1588v2, IEEE 802.1BA, Wi-Fi CERTIFIED 6 |
| Subtype |
Gigabit Ethernet |
| Features |
Access Control List (ACL) support, Quality of Service (QoS), Rapid Per-VLAN Spanning Tree Plus (PVRST+), Shaped Round Robin (SRR), PXE support, Energy-Efficient Ethernet, Class of Service (CoS), Flexible NetFlow (FNF), 802.1x authentication, DiffServ Code Point (DSCP) support, MACsec support, Control Plane Policing (CoPP), Blue Beacon LED, Zero-touch provisioning (ZTP), Secure Boot, Protocol Independent Multicast (PIM), First Hop Security (FHS), PVLAN support |
| Construction |
Original |
| Housing Type |
Rack mount |
| Remote Management Protocol |
SNMP 1, RMON 1, RMON 2, SNMP 3, SNMP 2c, CLI, NETCONF, RESTCONF, gRPC, IPv4, IPv6, YANG |
| Power Over Ethernet (PoE) |
PoE+ |
| Capacity |
IPv4 routes: 32000 |
