A9K-8T-L
The Cisco® ASR 9000 Series Ethernet Line Cards are the latest generation of service-provider-focused Carrier Ethernet line cards from Cisco. These line cards deliver economical, scalable, highly available, line-rate Ethernet and IP/Multiprotocol Label Switching (IP/MPLS) edge services. The Cisco ASR 9000 Series Line Cards A9K-8T-L and other Cisco ASR 9000 Series platform components are designed to provide the fundamental infrastructure for scalable Carrier Ethernet and IP/MPLS networks, supporting profitable business, residential, and mobile services.
| Part Number | A9K-8T-L |
| Product Description | 8-Port 10GE Low Queue Line Card, requires XFPs |
| Supported Devices | Cisco ASR 9000 Router |
| Connectivity | 10-Mbps, 100-Mbps, 1-Gbps, and 10-Gbps 802.3 Ethernet |
| Memory | 4 GB DRAM |
| Options | Each line card is available as either a low queue, base or extended line card. |
| Physical dimensions (H x W x D); weight | 14 x 1.72 x 20.5 in.(35.56 x 4.37 x 52.07 cm)
14 – 19 lb (6.35 – 8.62 kg) |
| Power | Maximum 350W – 630W (depending on the card type); typical 310W – 565W (depending on the card type) |
Supported Devices
| Model | Description |
| ASR-9010-DC | Cisco ASR 9010 DC chassis |
| ASR-9010-AC | Cisco ASR 9010 AC chassis |
| ASR-9010-AC-V2 | ASR 9010 AC Chassis with PEM Version 2 |
| ASR-9010-DC-V2 | ASR 9010 DC Chassis with PEM Version 2 |
| ASR-9006-DC | Cisco ASR 9006 DC chassis |
| ASR-9006-AC | Cisco ASR 9006 AC chassis |
| ASR-9006-AC-V2 | ASR 9006 AC Chassis with PEM Version 2 |
| ASR-9006-DC-V2 | ASR 9006 DC Chassis with PEM Version 2 |
Compare to Similar Items
| Product Code | A9K-8T-L | A9K-4T-L |
| Product Description | 8-Port 10GE Low Queue Line Card, requires XFPs | 4-Port 10GE Low Queue Line Card, requires XFPs |
| Supported Devices | Cisco ASR 9000 Router | Cisco ASR 9000 Router |
| Connectivity | 10-Mbps, 100-Mbps, 1-Gbps, and 10-Gbps 802.3 Ethernet | 10-Mbps, 100-Mbps, 1-Gbps, and 10-Gbps 802.3 Ethernet |
| Memory | 4 GB DRAM | 4 GB DRAM |
| Physical dimensions (H x W x D); weight | 14 x 1.72 x 20.5 in.(35.56 x 4.37 x 52.07 cm)
14 – 19 lb (6.35 – 8.62 kg) |
14 x 1.72 x 20.5 in.(35.56 x 4.37 x 52.07 cm)
14 – 19 lb (6.35 – 8.62 kg) |
