7600-ES20-GE3C Specification |
|
| General | |
| Device Type | Switch – 20 ports – L3 – managed – with Cisco Distributed Forwarding Card DFC-3C |
| Enclosure Type | Plug-in module |
| Subtype | Gigabit Ethernet |
| Compatible Slots | 1 x expansion slot |
| Ports | 20 x Gigabit SFP |
| MAC Address Table Size | 80K entries |
| Routing Protocol | GRE |
| Remote Management Protocol | SNMP, RMON, SMON |
| Features | Layer 3 switching, layer 2 switching, VLAN support, DiffServ support, Weighted Random Early Detection (WRED), LAN-to-LAN bridging, Access Control List (ACL) support, Quality of Service (QoS) |
| RAM | 512 MB |
| Status Indicators | Status |
| Expansion / Connectivity | |
| Interfaces | 20 x SFP (mini-GBIC) |
| Miscellaneous | |
| Compliant Standards | FCC Class A certified, CISPR 22 Class A, EN 60950, EN 61000-3-2, VCCI Class A ITE, IEC 60950, EN 61000-3-3, EN55024, EN55022 Class A, UL 60950, CSA 22.2 No. 60950, EN 61000-6-1, ACA TS001, AS/NZS 3260, AS/NZ 3548 Class A, FCC Part 15, ICES-003 Class A, EN300-386 |
| Dimensions & Weight | |
| Width | 15.4 in |
| Depth | 16 in |
| Height | 1.7 in |
| Weight | 16.09 lbs |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 104 °F |
| Humidity Range Operating | 10 – 90% |
