| Type |
Full HD Digital H.265 T2 Terrestrial/Cable Receiver with Built-in Conax Card Reader |
| Smart Card Slot |
One slot for Conax built-in smart card |
| USB Support |
2 high-speed USB 2.0 ports |
| External Infrared Port |
Yes |
| Time Shift Support |
Yes |
| Dolby Digital Bit-Stream Output |
Via digital video output |
| Supported Formats |
MKV, AVI, MPG, MP4, TS, VOB, JPEG & MP3 |
| Playback Support |
Yes |
| Software Upgrade |
Via USB |
| Standby Power Consumption |
Low |
| Tuner & Demodulation |
|
| Tuner Type |
DVB-T2 / DVB-C |
| Frequency Range |
48 MHz – 862 MHz |
| RF Input Level |
“-80dBm to -20dBm” |
| Antenna Output Power |
DC 5V at max 75mA, overload protection |
| Demodulation |
COFDM 1K, 2K, 4K, 8K normal and extended, 16K normal and extended, 32K normal and extended |
| Input Symbol Rate |
1.0 ~ 7.0 Ms/s |
| Constellations |
QPSK, 16QAM, 64QAM, 256QAM / Rotated and non-rotated |
| Guard Intervals |
1/4, 19/256, 1/8, 19/128, 1/16, 1/32, 1/128 |
| Code Rates |
1/2, 3/5, 2/3, 3/4, 5/6 |
| MPEG TS A/V Decoding |
|
| Transport Stream |
MPEG-2, MPEG-4, H.264, H.265 |
| Input Rate |
Max. 120Mbit/s |
| Aspect Ratio |
4:3, 16:9, Letter Box |
| Video Decoding |
MPEG-4 ASP, H.265 MP/HP@L4.1, MPEG-2 MP@HL/MP@ML, SMPTE421M/VC-1 WMV-9 AP@L3 |
| Video Resolution |
720x480p/i, 720x576p/i, 1280x720p, 1920x1080p/i |
| Audio Decoding |
AAC-LC, HE-AAC, LPCM, MP3, WMA, WAV |
| Audio Mode |
Left / Right / Stereo / Mono |
| Sampling Rate |
32, 44.1, and 48KHz |
| System Resources |
|
| Main Processor |
800 MHz |
| Flash Memory |
Serial Flash 8MB x 1 |
| DDR RAM |
DDRIII 1866 128MBx1 |
| A/V and Input/Output Data |
|
| Ethernet |
10/100M RJ45 |
| USB Ports |
Two USB 2.0 ports |
| Digital Video Output |
|
| S/PDIF |
Coaxial digital audio or Dolby Digital Bit Stream output |
| SCART |
(1-CVBS, 1-L/R, SL, FB), or RCA output |
| IR |
Jack-type, connector for external IR sensor |
| RS232 |
Jack-type, transmission speed 115.2Kbps, 9-pin D-sub type |
| Physical Specifications |
|
| Dimensions |
146mm x 110mm x 35mm |
| Net Weight |
0.25 kg |
